Electrical accessories for the "TRACK IN" track from ALS For the successful use of the built-in track, other components are required in addition to the rails themselves, depending on the requirements and specification. On our website you will find all components available via selection menus.The overview below will help you find the right parts using the picture list. Below the picture table you will find some application examples to help you configure your own. Pictures and selection of electrical accessories for ALS TRACK IN track see here: Planning example for the TRACK IN track: Example 1: Requirement: 3.70m track black, recessed mounting, end feedAt least the following are required: 2x 3 Phase construction rail 2m --> SCH-620 (1x shorten to 1.70m) Electrical straight connector --> SCH-132062 End feeder with ceiling cover --> SCH-132012 (depending on the orientation of the protective conductor) End cap for the other side --> SCH-032172 Example 2: Requirement: 2 x 90 ° arrangement of U-shaped busbar with the partial lengths 2m - 4m - 1.70m, white, feed in the middle of the 4m section, recessed mounting 2x 3 Phase construction rail 2m --> SCH-621N (1x kürzen auf 1,70m) 1x 3 Phase construction rail 4m --> SCH-641N 2x Corner connector protection inside --> SCH-132101N 1x DALI center feeder --> SCH-152031N 2x End cap --> SCH-032171N

Electrical accessories for DALI track "TRACK DALI" from ALS For the successful use of the DALI track, other components are required in addition to the tracks themselves, depending on the requirements and specification. On our website you will find all components available via selection menus.The overview below will help you find the right parts using the picture list. Below the picture table you will find some application examples to help you configure your own.For pictures and selection of electrical accessories for ALS DALI tracks, see here: Planning example for the DALI track: Example 1: Requirement: 3m power track black, surface mounting with DALI data bus, end feedAt least the following are required: 3 Phase construction rail 1m --> 225-102 3 Phase construction rail 2m --> 225-202 Electrical straight connector --> 555212062 End feeder with data bus --> 555212012 (depending on the orientation of the protective conductor) End cap for the other side --> SCH-012172 Example 2: Requirement: 2 x 90 ° arrangement of U-shaped busbar with partial lengths of 2m - 4m - 1m, white, feed in the middle of the 4m section, installation with DALI bus 1x 3 Phase construction rail 1m --> 225-101N 1x 3 Phase construction rail 2m --> 225-201N 1x 3 Phase construction rail 4m --> 225-401N 2x Corner connector protection Inside --> 555212101N 1x DALI center feeder --> 555252031N 2x endcap --> SCH-012171N

Electrical accessories for DALI track "TRACK ON" from ALS In addition to the rails themselves, other components depending on the requirements and specifications are necessary for the successful use of the surface-mounted track. On our website you will find all components available via selection menus.The overview below will help you find the right parts using the picture list. Below the picture table you will find some application examples to help you configure your own.Pictures and selection of electrical accessories for ALS TRACK ON tracks see here: lanning example for the TRACK ON track: Example 1: Requirement: 3m power track black, surface mounting, end feedAt least are needed: 3 Phase construction rail 1m --> SCH-102 3 Phase construction rail 2m --> SCH-202 Electrical straight connector --> SCH-112062 End feeder --> SCH-112012 (depending on the orientation of the protective conductor) End cap for the other side --> SCH-012172 Example2: Requirement: 2 x 90 ° arrangement of U-shaped busbar with the partial lengths 2m - 4m - 1m, white, feed in the middle of the 4m section, surface mounting 1x 3 Phase construction rail 1m --> SCH-101N 1x 3 Phase construction rail 2m --> SCH-201N 1x 3 Phase construction rail 4m --> SCH-401N 2x Corner connector protection Inside --> SCH-112101N 1x DALI center feeder --> SCH-152031N 2x End cap --> SCH-012171N

System components as accessories for DALI track "ONETRACK DALI" from ALS NEW: Eutrac changes its DALI rail system - ONETRACK by EUTRAC REPLACES EUTRAC 3 WITH DATA BU Attention: Please note the compatibility of DALI spotlights with the respective track systems (ONETRACK new, TRACK previously). For the successful use of the ONETRACK DALI power rail, other components are necessary in addition to the rails themselves, depending on the requirements and specifications. On our website you will find all available system components via the selection menus, you will find an overview in the download (data sheet for the various ONETRACK system components). The system components include the respective feeders (protective conductor on the right or left) as well as various connectors, each with a feed option. The following variants are available in white, grey, black: Straight connector, in all three colors I-connector, in all three colors I-connector with protective conductor on the outside, in all three colors L-connector with protective conductor inside, in all three colors FLEX connector, in all three colors T-connector with protective conductor inside right, in all three colors T-connector with protective conductor inside left, in all three colors T-connector with protective conductor outside right, in all three colors T-connector with protective conductor outside left, in all three colors X-Connect,r in all three colors Central feeder, in white and black Below the picture table you will find some application examples to help you with your own configuration. You can download the detailed instructions in the download area as a PDF file. Planning example for the DALI track: Example 1: Requirement: 3m black track, surface mounting with DALI data bus, end feed At least you need: 1x 3-phase mounting rail 1m --> 575 2 1101 2 1x 3-phase mounting rail 2m --> 575 2 1102 2 1x electrical longitudinal connector --> 575 2 12062 1x end feeder with data bus --> 575 2 1201 2(depending on the orientation of the protective conductor) 1x end cap for the other side --> 575 0 3217 2 Example 2: Requirement: 2 x 90° arrangement of U-shaped busbar with partial lengths of 2m - 4m - 1m, white, feed in the middle of the 4m section, structure with DALI bus 1x 3-phase mounting rail 1m --> 575 2 1101 6 1x 3-phase mounting rail 2m --> 575 2 1102 6 1x 3-phase mounting rail 4m --> 575 2 1142 6 2x corner connector protection. inside --> 575 2 32106 1x DALI center feeder --> 575 2 52036 2x end cap --> 575 0 3217 6

ALS Brick - LED linear light with adapter For mounting on 3-phase power rails. The lamp is available in white or black and offers the two most common light colors with 3,000k and 4,000k. Ballasts from well-known manufacturers such as Osram, Philips and Tridonic are installed. There are differences in performance, where a maximum of more than 8,000 lumens are achieved, and in the beam angle, where a distinction is made between medium-wide beam (30°), double asymmetric beam (60°) and wide beam (90°). Areas of application can be found in basic lighting in retail, in foyers or in rooms with higher ceilings. The efficient chip on board technology (COB) is also used here. More technical data   Luminaire type LED 3-phase linear light Manufacturer ALS Product name Brick Type Series - LED Type  COB LED Lifetime 40,000h Mounting 3-phase adapter Cooling Passive Agility rigid Material Die-cast aluminium, powder-coated Power in W 40W, 60W Performance values 4,500 - 8,050lm System efficiency 110 - 132 lm/W Light colors 3000k, 4000k Color rendering Ra > 80 Beam angle medium wide (30°)   wide (90°)   double symmetric (60° wallwash) Color white, black Dimmable no Protection class II degree of protection IP 20 Dimensions of lamp head L x Ø 1150x65mm Weight k. A Energy efficiency E On demand also available in CRI >90, housing color aluminum gray and dimmable with phase cut (trailing edge). Please be advised: The leakage current of each luminaire is 0,9 mA, therefore do not operate more than 10 luminaires via an RCD (Fi) circuit breaker 30 mA! For use without RCD (Fi) refer to the assembly instructions in the download tab.   For further data, please also refer to our download tab.

ONETRACK track system for all ALS DALI track lights, with data bus NEW: Eutrac changes its DALI rail system - ONETRACK by EUTRAC REPLACES EUTRAC 3 WITH DATA BUS The shape of the new ONETRACK power rails is based on the proven EUTRAC design and enables the use of the previous EUTRAC adapter. The ONETRACK DALI busbar system is ideal for the individual illumination of your premises for restaurants, shops, exhibitions and much more. Attention: Please note the compatibility of DALI spotlights with the respective track systems (ONETRACK new, TRACK previously). Thanks to the integrated DALI data bus, all dimming and scene options or grouping of the track spotlights used are available. Depending on the design of the busbar architecture, various electrical connectors for the function and various mounting accessories are provided. You can access all of the options offered directly via the links below and via the Recommendation tab. To simplify matters, we have created practical examples below to help you with configuration.   Technical features of the track system: Extruded aluminium profile Lengths from 1m to 4m selectable flush adapter available with and without ballast Ceiling mounted or pendant installation Traffic white RAL9016 or painted coated, or silver anodized Forward-looking 3-phase power rail with internal data bus ((DALI, DMX, others) Pre-punched slotted holes for installation Adaption of length by sawing 220-240 V Protection class: 1 Test certificate: CE Weight: 1 KG/Meter Surface: Die-cast aluminum Dimensions: L=1000/2000/3000/4000mm / W=31,4mm / H=37,35 mm Large selection of connectors, feeders and mounting accessories Planning example for the DALI track: Example 1: Requirement: 3m power track black, surface mounting with DALI data bus, end feed At least the following are required: 1x 3 phase rail 1m --> 575 2 1101 2 1x 3 phase rail 2m --> 575 2 1102 2 1x Longitudinal electrical connector --> 575 2 12062 1x End feeder with data bus --> 575 2 1201 2 (depending on the orientation of the protective conductor) 1x End cap for the other side --> 575 0 3217 2 Example 2: Requirement: 2 x 90 ° arrangement of U-shaped busbar with partial lengths of 2m - 4m - 1m, white, feed in the middle of the 4m section, installation with DALI bus 1x 3 phase rail 1m --> 575 2 1101 6 1x 3 phase rail 2m --> 575 2 1102 6 1x 3 phase rail 4m --> 575 2 1142 6 2x Corner connector protection. inside --> 575 2 32106 1x DALI Central feeder --> 575 2 52036 2x End cap --> 575 0 3217 6 Note: The power rail with length of 4,0m is also available on request. (Use "Question to product?"-Button)

BL-201-18-868 EUTRAC FLEX, EnOcean DALI controller for EUTRAC light rail with data bus The proven series of BL-201 EnOcean DALI gateways for flush-mounted installation or integration in luminaires offers the simplest way of connecting wireless communication based on EnOcean with DALI for connecting lighting technology. This product now supplements the series with a freely configurable lighting controller with the following essential features: Simple snapping into the DALI light rail 230 V AC supply voltage via light rail 1x DALI master Integrated DALI power supply for up to 15 DALI slaves (Iout max. = 30 mA) 1x EnOcean master, bidirectional (TCM310) Internal antenna PC configuration tool BL-PC-FLEX for wireless configuration of the control functions Useful for existing buildings and missing DALI bus from the switching unit to the luminaire unit. The function of the gateways with FLEX option is configured using the BL-201-FLEX PC software.In contrast to the other software options, instead of the fixed functions / assignments, e.g. groups and scenes can first be configured on the DALI. Then the assignment of one or more switches / rockers to the individual groups or scenes. The communication and The gateways are programmed wirelessly via an EnOcean USB stick.For beginners we recommend the starter kit, consisting of software and USB stick: #11228, BL-PC-FLEX setup kit for Windows PC

Fastening elements for DALI track "ONETRACK DALI" from Eutrac NEW: Eutrac changes its DALI rail system - ONETRACK by EUTRAC REPLACES EUTRAC 3 WITH DATA BU Attention: Please note the compatibility of DALI spotlights with the respective track systems (ONETRACK new, TRACK previously). For the successful use of the ONETRACK DALI power rail, other components are necessary in addition to the rails themselves, depending on the requirements and specifications. Here you will find a selection of the available fastening elements, an overview of all available products can be found in the download (data sheet fastening elements ONETRACK). The fasteners include various accessories: Ceiling clip 40 mm, made of galvanized steel as raw part Ceiling clip, 35 mm, made of aluminium, in black or white Retaining clip, 25 mm, made of aluminium, in black, white or raw Quick suspension, in black or white Aluminium splice retaining clip, available in black, white or raw Aluminium joint connectors, in black or white Hook for attachment to the power track, in black, white or grey

Installation of track with ceiling support (wing) The use of a conductor rail is inconspicuous when installed in z. B. suspended ceilings in connection with a ceiling support. This means that busbars are ideally suited for the individual illumination of the premises for restaurants, shops, exhibitions and much more. Depending on the design of the busbar architecture, various electrical connectors for the function and various mounting accessories are provided. You can access all of the options offered directly via the links below and via the Recommendation tab. To simplify matters, we have created practical examples below to help you with configuration. Technical characteristics of the installation busbars: Extruded aluminium profile Painted white or black Profiling for hanging spring clips 4 copper conductors (2,5 mm²)embedded in plastics Adaption of length by sawing 220-240 V max. 3 x 16 A Protection class: 1 Test certificate: CE Weight: 1,25 Kg / Meter Colour: white / black Surface: extruded aluminium Dimensions: L=2000/3000/4000mm / W=59mm / H=42mm Large selection of connectors, feeders and mounting accessories TRACK IN also available with DALI function with 6 copper conductors 2.5mm² on request Planning examples for track for ceiling installation: Example 1: Requirement: 3.70m power track black, recessed mounting (ceiling installation), end feed You will need at least: 2x Three-phase ceiling track 2m -> SCH-620 (1x shorten to 1.70m) 1x Longitudinal electrical connector --> SCH-132062 1x End feeder with ceiling cover --> SCH-132012 (depending on the orientation of the protective conductor) 1x End cap for the other side --> SCH-032172 Example 2: Requirement: 2 x 90 ° arrangement of the U-shaped busbars with partial lengths 2m - 4m - 1.70m, white, feed in the middle of the 4m section, recessed mounting (ceiling installation) 2x Installation of track 2m --> SCH-621N (1x shorten to 1,70m) 1x Installation of track 4m --> SCH-641N 2x Corner connector protection inside --> SCH-132101N 1x DALI central feeder --> SCH-152031N 2x End cap --> SCH-032171N Note: The power rail with length of 4,0m is also available on request. (Use "Question to product?"-Button)

LED Rail spotlight 30W MIO with COB technology MIO Rail spotlight - innovative design with integrated 3-phase electronic adapter. Used primarily for accent lighting, whereby various types of objects are to be staged at specific points. These COB-LED modules are equipped with the latest LED generation.   Technical features: Housing is made of die-cast aluminium (black/white) Can be rotated through 330° and pivoted through 130° COB module is available in 3 beam angles 15°/36°/60 With 3-phase electronic adapter Protection: IP20 Protection class: II Integrated electronic power supply Energy efficiency: A++ - A On request With DALI adapter (pending)     Light up with COB-LED* COB-LED* COB-LED* COB-LED* Colour temperature 2700K 3000K 3500K 4000K Beam angle 15° 36° 60° 15° 36°  60° 15° 36° 60° 15° 36°  60° Colour rendering index CRI >90 pivotable 130° 130° 130° 130° Luminous flux (lm) 2789 2943 2903 2900 3060 3019 2943 3105 3063 2944 3107 3065 System efficiency (lm/W) 81 86 85 85 89 88 86 91 81 86 91 89 System power 34W Connected load 30W Rail system EUTRAC Outside diameter H=129mm Dimension 91 mm *COB - LED stands for Chip-On-Board-LED. Many LED chips together create a LED area. Further information can be found in the datasheet for the 30Watt Series MIO rail spotlight in the Download tab.

LED Track light 34W with 40° beam angles - DALI DT8 / ZigBee dimmable K-FORUM is a high-quality track spotlight that can be used in a wide variety of LED lighting systems thanks to its simple, timeless design. To set the scene perfectly, the spotlight provides a clear ceiling image despite different lighting tasks. In addition there are extensive turning and swiveling ranges. K-FORUM has a highly transparent protective glass and, with its even light distribution, represents a complete and universally usable LED spotlight. Another highlight are the innovative control options of the K-FORUM: Smart lighting control with NeoLink / ZigBee Control of complex lighting systems with DALI DT8 Control via CASAMBI Product overview and features: Sleek design and clear silhouettes Three different beam angles Slewing range 355°, swivel range 180° Clear ceiling design despite different lighting tasks Functionality: Colour temperature 1,800 K to 16,000 K High colour stability from micro-controller controlled LED management with temperature compensation and factory calibration Soft light mixing and uniform light distribution Highly permeable safety glass Passive cooling including thermal management Mounting: Bus bar Ordering data for K-FORUM: The product is available in different versions depending on the control, beam angle and surface (white or silver). All track spotlights have integrated PI LEDs. Article number Categorization of the luminaire K-FO-40-NZ-W Spotlight / NeoLink, ZigBee / beam angle 40° / white K-FO-40-NZ-S Spotlight / NeoLink, ZigBee / beam angle 40° / silver K-FO-40-NZ-SZ Spotlight / NeoLink, ZigBee / beam angle 40° / black K-FO-40-DA-W Spotlight / DALI DT8 / beam angle 40° / white K-FO-40-DA-S Spotlight / DALI DT8 / beam angle 40° / silver K-FO-40-DA-SZ Spotlight / DALI DT8/ beam angle 40° / black K-FO-40-CA-W Spotlight / CASAMBI / beam angle 40° / white K-FO-40-CA-S Spotlight / CASAMBI / beam angle 40° / silver K-FO-40-CA-SZ Spotlight / CASAMBI / beam angle 40° / black Technical data for K-FO-xx-yy-z: Luminous source LED-Modul (PI-LED) Operating voltage 230 VAC Power 34 W Beam angle   40°   Luminous flux   2580 lm   Colour temperature 1800 K - 16000 K Colour rendering index (CRI) 90 Control NeoLink / ZigBee DALI DT8 CASAMBI Dimming range CCT/CIE-xy 5-100% RGB 0-100% Protection type IP20 Protection class SKI Service lifetime L80/B10 50000 h Bus bar NeoLink: GLOBAL GA 69 DALI DT8: EUTRAC MultiAdapterPlus Dimensions Ø 90 / 120 x 230 mm Note: The products of the manufacturer Kiteo are individually manufactured especially for you according to your specification. This also explains the longer delivery time of 1-3 weeks depending on the workload. For further information please refer to the data sheet in the Download tab.

LED track spotlights with DALIThis version of the BWS30 LED track spotlight features a DALI dimming function. It can be purchased in CoB LED module with 3 different beam angles (15°, 24° and 40°). The BWS30 has a housing made of painted die-cast aluminum and a clear protective glass. This LED track spotlight is available in 4 housing colors. Data for the BWS30 DALI track spotlight: Protection class I Supply voltage: 220-240V Integrated electronic power supply LED operating current: 700mA Eutrac®-3-phase electronic adapter CRI > 90 Energy efficiency: A++ -A  Variation-specific data of the LED track spotlight BWS30 with DALI dimming:  Color temperature 2700K 3000K 4000K Beam angle 15° 24° 40° 15° 24° 40° 15° 24° 40° Power 29W 29W 29W Luminous flux 2237lm 2255lm 2124lm 2350lm 2357lm 2232lm 2404lm 2402lm 2282lm Traversable angle 130° 130° 130° System efficiency 77lm/W 78lm/W 73lm/W 81lm/W 81lm/W 77lm/W 83lm/W 83lm/W 79lm/W UGR 19.35 18.45 18.80 19.55 18.60 18.95 19.65 18.70 19.05 Dimension (H x W) 176mm x 126mm 176mm x 126mm 176mm x 126mm Outer diameter 79mm 79mm 79mm

LED track spotlightsThis version of the BWS series is available in CoB LED module with 3 different beam angles (15 °, 24 ° and 40 °). In addition, you can choose the LED track spotlight from 4 color combinations. The housing is made of painted die-cast aluminum with clear protective glass. Data for the BWS30 track spotlight: Protection class I Supply voltage: 220-240V Integrated electronic power supply LED operating current: 700mA Eutrac®-3-phase electronic adapter CRI > 90 Energy efficiency: A++ -A  Ideal for lighting food (vegetables, meat and bakery products) and is also used in shops for object lighting. In particular, due to the very good color rendering index, it is ideal for eg clothing stores. Variation-specific data of the LED track spotlight BWS30:  Color temperature 2700K 3000K 4000K Beam angle 15° 24° 40° 15° 24° 40° 15° 24° 40° Power 29W 29W 29W Luminous flux 2237lm 2255lm 2124lm 2350lm 2357lm 2232lm 2404lm 2402lm 2282lm Traversable angle 130° 130° 130° System efficiency 77lm/W 78lm/W 73lm/W 81lm/W 81lm/W 77lm/W 83lm/W 83lm/W 79lm/W UGR 19.35 18.45 18.80 19.55 18.60 18.95 19.65 18.70 19.05 Dimension (H x W) 176mm x 126mm 176mm x 126mm 176mm x 126mm Outer diameter 79mm 79mm 79mm

LED track spotlightsThis version of the BWS series is available in CoB LED module with 3 different beam angles (15 °, 24 ° and 40 °). In addition, you can choose the LED track spotlight from 4 color combinations. The housing is made of painted die-cast aluminum with clear protective glass. Data for the BWS30 track spotlight: Protection class I Supply voltage: 220-240V Integrated electronic power supply LED operating current: 700mA Eutrac®-3-phase electronic adapter CRI > 90 Energy efficiency: A++ -A  Ideal for lighting food (vegetables, meat and bakery products) and is also used in shops for object lighting. In particular, due to the very good color rendering index, it is ideal for eg clothing stores. Variation-specific data of the LED track spotlight BWS30:  Color temperature 2700K 3000K 4000K Beam angle 15° 24° 40° 15° 24° 40° 15° 24° 40° Power 29W 29W 29W Luminous flux 2237lm 2255lm 2124lm 2350lm 2357lm 2232lm 2404lm 2402lm 2282lm Traversable angle 130° 130° 130° System efficiency 77lm/W 78lm/W 73lm/W 81lm/W 81lm/W 77lm/W 83lm/W 83lm/W 79lm/W UGR 19.35 18.45 18.80 19.55 18.60 18.95 19.65 18.70 19.05 Dimension (H x W) 176mm x 126mm 176mm x 126mm 176mm x 126mm Outer diameter 79mm 79mm 79mm

LED track spotlights with DALI This version of the BWS30 LED track spotlight features a DALI dimming function. It can be purchased in CoB LED module with 4 different beam angles (15°, 24°, 40° and 60°). The BWS30 has a housing made of painted die-cast aluminum and a clear protective glass. This LED track spotlight is available in 4 housing colors. Data for the BWS30 DALI track spotlight: Protection class I Supply voltage: 220-240V Integrated electronic power supply LED operating current: 700mA Eutrac®-3-phase electronic adapter CRI > 90 Energy efficiency: A++ -A Attention: Is available in CRI97 on demand Ideal for lighting food (vegetables, meat and bakery products) and is also used in shops for object lighting. In particular, due to the very good color rendering index, it is ideal for eg. clothing stores. Variation-specific data of the LED track spotlight BWS30 with DALI dimming:    Colour temperature    2700K    3000K 3500K 4000K Beam angle 15° 24° 40° 60° 15° 24° 40° 60° 15° 24° 40° 60° 15° 24° 40° 60° System power 26W 26W 26W 26W Luminous flux (lm) 2290 2276 2342 2315 2382 2367 2436 2408 2417 2401 2473 2443 2418 2403 3135 2445 pivotable 130° 130° 130° 130° System efficacy (lm/W) 89 88 91 90 92 92 95 93 94 93 96 95 94 93 96 95 UGR 19,35 18,45 18,80 * 19,55 18,60 18,95 * * * * * 19,65 18,70 19,05 * Dimensions (H x B) 176mm x 126mm 176mm x 126mm    176mm x 126mm   176mm x 126mm   Outside diameter 79mm 79mm 79mm 79mm * Data not available yet For further information please refer to the data sheet in the Download-Tab.

LED Tracking Spotlights The Tracking spotlights MAYA by A.L.S. with 19W is availabel in 4000K and with a CRI>90. Thiees lights are flexible rotatable 100° and offera beam angle 24°. Technical Data Lightning with  CoB-LED System power  19 W Lumious flux  1666 lm Colour temperature  2700 K Colour rendering-Index  CRI >90 beam angle Power supply  incl. power supply Operating power  500 mA System efficiency  88 lm/W Protection class 2 Weight  0,887 kg Colour  white Material  Boxing from Alu-die casting

Mounting accessories for ALS track system TRACK (DALI / ON / IN) In addition to the electrical connectors and feeders for the ALS track system TRACK DALI, TRACK ON and TRACK IN, different fastening elements are required depending on the location. On this page you will find a comprehensive overview of accessories for pendulum mounting (rope suspension, pipe pendulum suspension, etc. ). as well as Gripper with conductor rail clip, or ceiling clips, butt connectors, universal hooks, socket adapters and much more.A detailed overview can be found on the catalog page as a PDF file in the download segment.Via our selection menu, the respective selection depending on the colours is possible.

Odoin XS Trackspot These trackspots are available in 3000K and 4000K, with 27.0W depending on the version and different dimming options, CRI types. The corresponding tracks can be found here. Get to know the LUXEON STYLIST series LUXEON Stylist series LEDs have been developed explicitly for restaurants, grocery and fashion stores. Various innovative technologies are used for this purpose. Ask our sales department which solution will best showcase your products. New standards require new LEDs The Illuminating Engineering Society (IES) has published a technical memorandum that also includes a new method for measuring color rendering. The new TM-30-15 color standard promises to replace the color rendering index CRI as a color parameter. Various stability and spectrum parameters as well as a new set of color samples have been introduced which are more representative for real-world objects than the paste samples used for the CRI parameters. The new color parameters also better represent LED-based solid state lighting (SSL). The Television Lighting Consistency Index (TLCI) Studies have shown that the industrial color rendering index CRI is not well suited for television because of the so-called floating white point. The new index TLCI imitates a complete television camera and screen setting and takes into account the specific properties of the devices that influence color performance. The TLCI is only calculated using software. The only hardware required is a spectroradiometer to measure the spectral energy spread of the test fixture and a computer for the analysis program to perform the calculations. A light well with a high TLCI value enables the user to save costs, as no subsequent colour corrections are necessary. The most important features of the Odoin XS Trackspots: Housing colour XX=65 Matt white / White XX=66 Matt white / Blue XX=61 Matt white / Gold XX=63 Matt white / Silver XX=64 Matt white / Copper XX=62 Matt white / Black XX=85 Matt grey / White XX=86 Matt grey / Blue XX=81 Matt grey / Gold XX=83 Matt grey / Silver XX=84 Matt grey / Copper XX=82 Matt grey / Black XX=76 Matt black / White XX=77 Matt black / Blue XX=71 Matt black / Gold XX=74 Matt black / Silver XX=75 Matt black / Copper XX=72 Matt black / Black Material Housing: Die-cast aluminium Reflector glass: Polycarbonate Dimensions 107 mm x 100 mm Trackhight 14 mm Usage Indoors Beam angle(FWHM) 18° / 37° / 60° CRI / Ra (typ.) 97 / 80 Colour Consistency (MacAdam) SDCM3 IP Code IP20 / IP44 IK Code IK03 Operating temperature (Ta) -20°C / +45°C Life time at 25°C L70B50 131.000 h L80B50 80.000 h L90B50 35.000 h Safety signs EN60598 / EN62031 / EN62471 EMV-Directive EN55015 Guarantee 7 years Energy class A+ Odoin XS Convenient shopping with Crispcolor TechnologyTM In the world of retail, a good appearance is everything. Whether in an exclusive boutique or a large chain store: the importance of appropriate lighting for the store cannot be overestimated. The LUXEON Stylist range for fashion retail produces brighter, more vibrant whites and fuller colours to show your merchandise in the best possible light. The CrispColor and CrispWhite technologies replace previous halogen, metal halide and incandescent lamps. The LUXEON Stylist series provides exceptional lighting that will impress your customers. Bright Clothes; The Crispwhite TechnologyTM Only deep blue LEDs activate the Fluorescent Whitening Agents (FWAs), which are contained in almost all textiles and fabrics of all colours. CrispWhite Technology uses a patented double-peak technology in the violet spectrum to make textile products appear even brighter and more attractive - and this (in contrast to the use of UV light) without any risk to health. Atmoshere TechnologyTM for the perfect dinner Whether it's an elegant restaurant with white tablecloths or a cosy café, more and more restaurants are striving to inspire with an extraordinary ambience. Forward-thinking restaurant owners understand that the right lighting plays a very important role in this. The LUXEON Stylist range helps to create an unprecedented feel-good aesthetic in your restaurant without compromising efficiency. That's because the LEDs are equipped with AtmoSphere Technology and consume less energy and have a much longer life than traditional light sources. At the same time, the lamps generate less heat, which helps to reduce cooling costs, especially in warmer climates. Fresher food - thanks to Freshfocus TechnologyTM The LUXEON Stylist series whets your appetite! Grocery retailers know that the fresh food department in their store attracts customers and should therefore be attractively staged. Optimizing the saturation of the most dominant colors in the product range will result in more impulse purchases, higher sales and a lower end-of-day disposal rate. FreshFocus Technology therefore helps to accentuate the freshness of food. For example, you can emphasize the red tones in the meat department, increase the appetite for bread or baked goods or present fish in natural colors. LED lighting also saves energy and reduces environmental impact. Odoin XS Dimmability Non dimmable DALI Casambi Art.No. 350403XXHK02 350403XXHG02 350403XXHN02 350403XXE402 350403XXE102 350403XXE702 350403XXJ402 350403XXJ102 350403XXJ702 Colour temperature 3000 K 4000 K 3000 K 4000 K 3000 K 4000 K Luminous flux 3000 lm 3400 lm 3000 lm 2150 lm 3400 lm 3000 lm 2150 lm 3400 lm CRI 82 97 82 97 82 97 82 Lm/W (with EVG) 111 72 126 111 80 126 111 80 126 Type Integrated PSU Input 700 mA Power 27,0 W 41,7 W 27,0 W Input 5A 50µS Protection class I Pf 0,97 Note: This table shows only the versions with a beam angle of 18°; for other beam angles, please refer to the respective data sheet. For data sheets of the Trackspot Odoin XS series please see the Download tab: Note: The products of the manufacturer Illuxtron are individually manufactured according to your specification especially for you. This also explains the longer delivery time of 1-3 weeks depending on workload.

System components as accessories for DALI track "ONETRACK DALI" from ALS NEW: Eutrac changes its DALI rail system - ONETRACK by EUTRAC REPLACES EUTRAC 3 WITH DATA BU Attention: Please note the compatibility of DALI spotlights with the respective track systems (ONETRACK new, TRACK previously). For the successful use of the ONETRACK DALI power rail, other components are necessary in addition to the rails themselves, depending on the requirements and specifications. On our website you will find all available system components via the selection menus, you will find an overview in the download (data sheet for the various ONETRACK system components). The system components include the respective feeders (protective conductor on the right or left) as well as various connectors, each with a feed option. The following variants are available in white, grey, black: Straight connector, in all three colors I-connector, in all three colors I-connector with protective conductor on the outside, in all three colors L-connector with protective conductor inside, in all three colors FLEX connector, in all three colors T-connector with protective conductor inside right, in all three colors T-connector with protective conductor inside left, in all three colors T-connector with protective conductor outside right, in all three colors T-connector with protective conductor outside left, in all three colors X-Connect,r in all three colors Central feeder, in white and black Below the picture table you will find some application examples to help you with your own configuration. You can download the detailed instructions in the download area as a PDF file. Planning example for the DALI track: Example 1: Requirement: 3m black track, surface mounting with DALI data bus, end feed At least you need: 1x 3-phase mounting rail 1m --> 575 2 1101 2 1x 3-phase mounting rail 2m --> 575 2 1102 2 1x electrical longitudinal connector --> 575 2 12062 1x end feeder with data bus --> 575 2 1201 2(depending on the orientation of the protective conductor) 1x end cap for the other side --> 575 0 3217 2 Example 2: Requirement: 2 x 90° arrangement of U-shaped busbar with partial lengths of 2m - 4m - 1m, white, feed in the middle of the 4m section, structure with DALI bus 1x 3-phase mounting rail 1m --> 575 2 1101 6 1x 3-phase mounting rail 2m --> 575 2 1102 6 1x 3-phase mounting rail 4m --> 575 2 1142 6 2x corner connector protection. inside --> 575 2 32106 1x DALI center feeder --> 575 2 52036 2x end cap --> 575 0 3217 6

Universal LED driver with integrated Casambi module for use on conductor rails Features of the TCI driver Multipower device supplied with dip-switch for the selection of the output current with integrated wireless CASAMBI module A new breakthrough in luminaire design Puts the luminaire design first High power available in a very reduced space Easy to mount through inventive nipple design Active Power Factor Corrector Class II protection against electric shock for direct or indirect contact Current regulation ±5/6 % including temperature variations Output push-in terminal blocks: 0,2...0,5 mm2 Protections: against overheating and short circuit against mains voltage spikes against overload Thermal protection = C.5.a.  Technical data: Dip-SW Power Voltage out Current out Position 1 14 W 20...44V 325 mA const. Position 2 15,5 W 20...44V 350 mA const. Position 3 16,5 W 20...44V 375 mA const. Position 4 17,5 W 20...44V 400 mA const. Position 5 18,5 W 20...44V 425 mA const. Position 6 19,5 W 20...44V 450 mA const. Position 7 21 W 20...44V 475 mA const. Position 8 22 W 20...44V 500 mA const. Position 9 23 W 20...44V 525 mA const. Position 10 24 W 20...44V 550 mA const. Position 11 25 W 20...44V 575 mA const. Position 12 26,5 W 20...44V 600 mA const. Position 13 27,5 W 20...44V 625 mA const. Position 14 28,5 W 20...44V 650 mA const. Position 15 29,5 W 20...44V 675 mA const. Position 16 31 W 20...44V 700 mA const.The TCI Casambi busbar is available in:- 127634 white- 127635 grey- 127636 blackFurther details can be found in our downloads.

Conductor railsystem for all ALS DALI track lights, with data bus Attention: Please note the compatibility of DALI spotlights with the respective track systems, as EUTRAC has changed its DALI track system (ONETRACK new, TRACK previously). Conductor rail systems are ideal for the individual lighting of your premises for gastronomy, shops, exhibitions and much more. Thanks to the integrated DALI data bus, all dimming and scene options or grouping of the track spotlights used are available. Depending on the design of the busbar architecture, various electrical connectors for the function and various mounting accessories are provided. You can access all of the options offered directly via the links below and via the Recommendation tab. To simplify matters, we have created practical examples below to help you with configuration. Technical features of the track system: Extruded aluminium profile Lengths from 1m to 4m selectable Ceiling mounted or pendant installation Traffic white RAL9016 or painted coated, or silver anodized 4 copper conductors (2,5 mm²) embedded in plastics + two data conductors (DALI, DMX, 0-10 V, KNX) Pre-punched slotted holes for installation Adaption of length by sawing 220-240 V max. 3 x 16 A Protection class: 1 Test certificate: CE Weight: 1 KG/Meter Surface: Die-cast aluminum Dimensions: L=1000/2000/3000/4000mm / W=36mm / H=32 mm Large selection of connectors, feeders and mounting accessories Planning example for the DALI track: Example 1: Requirement: 3m power track black, surface mounting with DALI data bus, end feed At least the following are required: 1x 3 phase rail 1m --> 225-102 1x 3 phase rail 2m --> 225-202 1x Longitudinal electrical connector --> 555212062 1x End feeder with data bus --> 555212012 (depending on the orientation of the protective conductor) 1x End cap for the other side --> SCH-012172 Example 2: Requirement: 2 x 90 ° arrangement of U-shaped busbar with partial lengths of 2m - 4m - 1m, white, feed in the middle of the 4m section, installation with DALI bus 1x 3 phase rail 1m --> 225-101N 1x 3 phase rail 2m --> 225-201N 1x 3 phase rail 4m --> 225-401N 2x Corner connector protection. inside --> 555212101N 1x DALI Central feeder --> 555252031N 2x End cap --> SCH-012171N Note: The power rail with length of 4,0m is also available on request. (Use "Question to product?"-Button)

Power-track-system for ALS track luminaires, without data bus With a track system you can illuminate your premises completely individually, whether gastronomy, shops, exhibitions and much more. Depending on the design of the busbar architecture, various electrical connectors for the function and various mounting accessories are provided. You can access all of the options offered directly via the links below and via the Recommendation tab. To simplify matters, we have created various examples with a shopping list for you below. Technical features: Extruded aluminium profile Lengths from 1m to 4m selectable Ceiling mounted or pendant installation traffic white RAL 9016 or black coated, or anodized 4 copper conductors (2,5 mm²)embedded in plastics Pre-punched slotted holes for installation Adaption of length by sawing 220-240 V max. 3 x 16 A Protection class: 1 Test certificate: CE Weight: 1 KG/Meter Surface: extruded aluminium Dimensions: L=1000/2000/3000/4000mm / B=36mm / H=32 mm Large selection of connectors, feeders and mounting accessories Planning example for the TRACK ON track: Example 1: Requirement: 3m track black, surface mounting, end feed You will need at least: 1x 3 phase track 1m --> SCH-102 1x 3 phase track 2m --> SCH-202 1x longitudinal electrical connector --> SCH-112062 1x end feed  --> SCH-112012 (depending on the orientation of the protective conductor) 1x End cap for the other side --> SCH-012172 Example 2: Requirement: 2 x 90 ° arrangement of U-shape busbar with partial lengths of 2m - 4m - 1m, white, feed in the middle of the 4m section, surface mounting: 1x 3 phase track 1m --> SCH-101N 1x 3 phase track 2m --> SCH-201N 1x 3 phase track 4m --> SCH-401N 2x corner connector protection Inside --> SCH-112101N 1x DALI central feeder --> SCH-152031N 2x end cap --> SCH-012171N Note: The power rail with length of 4,0m is also available on request. (Use "Question to product?"-Button)
