IP54 Protection Coverage K-SPOT FLAT
Product information "IP54 Protection Coverage K-SPOT FLAT"
IP54 Protection Coverage K-SPOT FLAT
The IP54 protection cover increases the protection rating of your K-Spot-Flat from IP 30 to IP54
This means: 3 = Protected against solid foreign objects with diameter > 2. 5 mm
0 = No protection against water
With the protective cover you can increase the protection class to IP54:
5 = complete protection against contact or dust
4 = Protection against all-sided splash water
| Application/IP-Code: | IP5x |
|---|
Login
sw_related
K-SPOT FLAT 14W DALI DT8 / ZigBee
€260.61*
Highly efficient LED recessed luminaire K-SPOT FLAT 14W - DALI DT8 / ZigBee 3.0 dimmable
With its flat design, this compact LED recessed luminaire is perfectly suitable for a wide variety of indoor applications. Not only does it have a high level of efficiency, it also has microcontroller-controlled LED management, including factory calibration and temperature compensation. This results in a high colour location stability. In addition to functions such as modular dimming, the uniform light distribution and soft light mixing ensure optimum flexibility in LED lighting systems.
Another highlight are the innovative control options of the K-SPOT FLAT:
Smart lighting control with NeoLink / ZigBee
Control of complex lighting systems with DALI DT8
Product overview and features of the K-SPOT FLAT:
Compact and timeless design
Soft light mixing and uniform light distribution
High optical efficiency due to integrated anti-glare reflectors
High colour stability from micro-controller controlled LED management with temperature compensation and factory calibration
Features:
Colour temperature 1,800 K – 16,000 K
Modular Dimming
Camera Ready
LMU case with strain relief
Integrated aluminium heat sink
Operating temperature monitoring with automatic dimming function
Installation instructions:
It is a recessed luminaire with a small size, which means that only small installation depths are required (minimum installation depth 45 mm). Tool-free assembly is also possible. It is made using 2 fastening springs for 1 - 15 mm ceiling thickness.
Technical data:
Article number
K-DL-FLAT531
K-DL-FLAT534
K-DL-FLAT831
K-DL-FLAT834
Luminous source
LED-Modul (PI-LED)
Operating voltage
230 VAC (inkl. externer Konverter)
Power
14 W
Luminous flux
880 lm
Colour temperature
1800 K - 16000 K
Colour rendering index (CRI)
90
Control
ZigBee 3.0
DALI DT8
Dimming range
1% - 100%
Housing colour
white (RAL 9003)
brushed Aluminium
white (RAL 9003)
brushed Aluminium
Protection type
IP30
Protection type
SKII
Service lifetime
L80/B10 50000 h
Dimensions
95 x 95 x 45,5 mm (L * W * H)
Note:
The products of the manufacturer Kiteo are individually manufactured especially for you according to your specification. This also explains the longer delivery time of 1-3 weeks depending on the workload.
For further information please refer to the data sheet in the Download tab.
Variants from €284.41*
