LED Wall light Wash24
Product information "LED Wall light Wash24"
LED wall light for architectural lighting design
The version with transparent ultra-white glass shades and adjustable asymmetrical parabolic reflectors emits a direct, sharp and incisive light.It is quite simple to adjust the reflector: adjustment can be made even if the light is on. Unscrew, lift the reflector, turn 180° and screw. This allows the light to be applied to the wall, with the wall-washer effect accentuated, or outwards e.g. be directed to the illumination of sidewalks.
General features:
- Opal glass and linear LED module
- Clear glass and Power LED
- Rear cable entry
- Surface treatment of aluminium: pickling+ phosphorus chromate + epoxy coating + varnish with UV-stabilized epoxy powder
- Housing colours white, graphite grey and metal grey
- Protection type: IP65
- Protection class: I
- Built-in electronic power supply
Technical data:
| Light up with | Linear LED module | Power-LED | ||
| Quantity lamps | 1 | 2 | 1 | 2 |
| System power | 9,3 W | 9,5 W | ||
| Colour temperature | 3000K / 4000K | 3000K / 4000K | ||
| Operating current | 500mA | 350mA | ||
| Luminous flux | 513 lm | 1394 lm | 930 lm | 1860 lm |
| Connection voltage | 230 V | |||
| Colour rendering index | CRI >80 | |||
| System efficacy | 55 lm/W | 75 lm/W | 98 lm/W | |
| Energy efficacy | A++ - A | |||
| Mechanical load | IK08 | |||
| Protection type | IP65 | |||
| Protection class | I | |||
| Dimensions | L=222*W=116*H=100 mm | |||
| Weight | 2,02 kg | |||
For further information please refer to the data sheet in the Download-tab.
| Application/IP-Code: | IP65/67 (Outdoor) |
|---|---|
| Color Temperature/Color: | 3000K, 4000K |
Login
sw_similar
LED Wall Light K3-Writer
€546.76*
LED Wall Light K3-Writer for unlimited creativity
The new K3 Writer has been created to allow the maximum creative freedom.
Three casings, each with a 70 ° light distribution, one opening in all directions adjustable, or two opposite openings 45 ° up / down and right / left adjustable, or with 4 openings.
Combinable with 2 converging lenses, 2 thin masks (gobos) and 4 different coloured filters ,which allow allow innumerable light and color effects to accentuate architectural details on buildings.
Special attention is paid to the construction of aluminium or stainless steel AISI 316L, the milled tempered glass in line with the frame border and on installation and adjustment friendly handling.
With protection class II and IP65 the luminaires are suitable to to orient the fixture to any direction and install on any type of surface (wall, ceiling, floor) . To increase the wallwasher effect, the LED can be adjusted by 10 ° to the wall.
General features:
Optical lenses and shaping discs for every light emission to create special effects
Ceiling and wall mounting, in the garden also floor mounting
Rear cable entry
LED with 50,000 h lifetime and max. Lumen drop of 30%
Built-in driver
Manufactured in compliance with European standards EN 60598-1:2015
Version with 3000K or 4000K
Technical Data:
Light up with
LED
LED
LED
Quantity lamps
1
2
4
System power
6,4 W
12,8 W
25,6 W
Beam angle
70°
70°- 70°
4x70°
Operating current
500 mA
Connection voltage
230V
Colour rendering index
CRI > 85
Mechanical load
IK08
Energy efficacy
A++ - A
Protection type
IP65
Protection class
II
Dimensions
L=160*B=182*H=160 mm
For further information please refer to the data sheet in the Download-tab.
Variants from €647.96*
K3 MiniLED Wall Light with IP65
€217.89*
LED Wall Light with IP65 protection for special light effects
A small lighting cube containing the magic effects of the last generation power leds. he best efficiency and its 50.000 hour life permit K3 Miniled to be the winning match wherever energy saving and non-invasive look are required.
For outdoor as usual but for indoor as well when the light is the main feature. The combination of the light beam sis veratile. K3 MiniLed includes 3 lights, either just one opening, or two opposite openings, or four openings. There are two different beam angles: 30 and 70 °.
The construction is in primary aluminium - three colors.
K3 Miniled is IP65 absolutely waterproof and can be oriented everywhere - towards down, up or 45°. Suitable to be installed in any surface - wall floor and ceiling.
General features:
Light emission with clear marking of the light
Ceiling and wall mounting, in the garden also floor mounting
Rear cable entry
Wall light with IP65 protection
LED with 50,000 h lifetime and max. Lumen drop of 30%
Built-in driver
Manufactured in compliance with European standards EN 60598-1:2015
Version with 3000K or 4000K, 1 to 4 light emissions, different beam angles
Technical data:
Light up with
LED
LED
LED
Quantity lamps
1
2
4
System power
3 W
6 W
12 W
Beam angle
30° / 70°
30°- 30° / 70°- 70° / 30°- 70°
4x30° / 4x70°
Operating current
700 mA
Connection voltage
230V
Colour rendering index
CRI > 85
Mechanical load
IK08
Energy efficacy
A++ - A
Protection type
IP65
Protection class
II
Dimensions
L=100*W=102*H=100 mm
For further information please refer to the data sheet in the Download-tab.
Variants from €310.00*
LED Wall light K3-Power
€572.40*
LED exterior wall light K3-Power for optimal light outputK3 Power comes with a wide range of parabolic reflectors designed on the base of a dedicated optical project and produces interesting light efficiency, until 69%. Three housings with one, two or four openings and two different light beams (20 ° and 50 °) enable the design of attractive lighting effects.The aluminum housing is available in three different colours, the discs are flush mounted with the frame. Suitable to any installation surface – wall, floor and ceiling – is absolutely waterproof and can be oriented in any direction – up, down, 45°.
General features:
Structure: diffuser in tempered glass, ultrawhite. Housing made of die-cast aluminum with reduced copper content or AISI 316L stainless steel. Colour-matched hexagon screws
Internal optics made of polished Al 98.8 to emphasize the light beam
With the additional equipment A-K3 Power the lamp is adjustable
Ceiling and wall mounting, in the garden also floor mounting
Rear cable entry
LED with 50,000 h lifetime and max. Lumen drop of 30%
Built-in driver
Manufactured in compliance with European standards EN 60598-1:2015
Version with 3000K or 4000K, different housing colours and light emissions
Light up with
LED
LED
Quantity lamps
1
2
Beam angle
20° / 50°
20°-20° / 50°-50° / 20°-50°
System power
9,5W
2 x 9,5W
Operating current
500mA
Connection voltage
230V
Colour rendering index
CRI > 85
Mechanical load
IK08
Energy efficacy
A++ - A
Protection type
IP65
Protection class
II
Dimensions
L=160*W=182*H=160 mmFor further information please refer to the data sheet in the Download-tab.On request:Furthermore, it is possible to extend the wall external light K3-Power with the following accessories.
Description
Article number
Articulated bracket
Z-BK3POWER
Spike
S-K3POWER
Anti-dazzling flanged louvers
Z-AK3POWER
Stainless steel plate
A-K3POWER
Variants from €666.70*
LED Wall light Wash22
€344.09*
LED wall light for architectural lighting design
The version with transparent ultra-white glass shades and adjustable asymmetrical parabolic reflectors emits a direct, sharp and incisive light.
It is quite simple to adjust the reflector: adjustment can be made even if the light is on. Unscrew, lift the reflector, turn 180° and screw. This allows the light to be applied to the wall, with the wall-washer effect accentuated, or outwards e.g. be directed to the illumination of sidewalks.
General features:
Opal glass and linear LED module
Clear glass and Power LED
Rear cable entry
Surface treatment of aluminium: pickling+ phosphorus chromate + epoxy coating + varnish with UV-stabilized epoxy powde
Housing colours white, graphite grey and metal grey
Protection type: IP65
Protection class: I
Built-in electronic power supply
Technical data:
Light up with
Linear LED module
Power-LED
Quantity lamps
1
2
1
2
System power
9,3 W
9,5 W
Colour temperature
3000K / 4000K
3000K / 4000K
Operating current
500mA
350mA
Luminous flux
513 lm
1026 lm
930 lm
1860 lm
Connection voltage
230 V
Colour rendering index
CRI >80
System efficacy
55 lm/W
98 lm/W
Energy efficacy
A++ - A
Mechanical load
IK08
Protection type
IP65
Protection class
I
Dimensions
L=222*W=116*H=100 mm
Weight
2,148 kg
For further information please refer to the data sheet in the Download-tab.
Variants from €351.05*
LED Wall light Wash24
€316.57*
LED wall light for architectural lighting design
The version with transparent ultra-white glass shades and adjustable asymmetrical parabolic reflectors emits a direct, sharp and incisive light.
It is quite simple to adjust the reflector: adjustment can be made even if the light is on. Unscrew, lift the reflector, turn 180° and screw. This allows the light to be applied to the wall, with the wall-washer effect accentuated, or outwards e.g. be directed to the illumination of sidewalks.
General features:
Opal glass and linear LED module
Clear glass and Power LED
Rear cable entry
Surface treatment of aluminium: pickling+ phosphorus chromate + epoxy coating + varnish with UV-stabilized epoxy powder
Housing colours white, graphite grey and metal grey
Protection type: IP65
Protection class: I
Built-in electronic power supply
Technical data:
Light up with
Linear LED module
Power-LED
Quantity lamps
1
2
1
2
System power
9,3 W
9,5 W
Colour temperature
3000K / 4000K
3000K / 4000K
Operating current
500mA
350mA
Luminous flux
513 lm
1394 lm
930 lm
1860 lm
Connection voltage
230 V
Colour rendering index
CRI >80
System efficacy
55 lm/W
75 lm/W
98 lm/W
Energy efficacy
A++ - A
Mechanical load
IK08
Protection type
IP65
Protection class
I
Dimensions
L=222*W=116*H=100 mm
Weight
2,02 kg
For further information please refer to the data sheet in the Download-tab.
Variants from €362.95*
